Frozen Asparagus Freezing Machine

The conveyor belt of this frozen asparagus freezing machine is stepless speed regulation, and the freezing time can be adjusted according to different materials.

Description

The frozen asparagus freezing machine provided by our company has the advantages of simple and reasonable structure design, good frozen product quality, low energy consumption, and high quick freezing efficiency. It is a freezer commonly used in commercial frozen fruit and vegetable products. Suitable for large-scale food processing plants, frozen processing of fruit and vegetable processing, etc.


In addition, we also provide a complete asparagus freezing production line, whose processing flow mainly includes: asparagus---washing---blanching---air drying---precooling---freezing---packaging.



Main Features of Frozen Asparagus Freezing Machine


1. Strong cold air flow with a stable and large flow rate can ensure reasonable air distribution and uniform air distribution.

2. The material does not agglomerate or stick to the mesh belt during the freezing process.

3. The fully fluidized freezing process is realized, which greatly improves the freezing quality and yield of asparagus.

4. The fluidized bed is circulating, the mesh belt runs smoothly, and the conveying speed is adjustable.

5. It can accommodate tray carts for freezing tray-loaded frozen products. Very versatile.

6. Can freeze a variety of vegetables, fruits, seafood, pasta, etc.



Technical Parameter



ModelsIQF-100IQF-200IQF-300IQF-400IQF-500IQF-1000IQF-2000IQF-3000
Capacity100KG/H200KG/H300KG/H400KG/H500KG/H1000KG/H2000KG/H3000KG/H
Refrigeration Power20KW36KW54KW72KW90KW180KW340KW540KW
Size(L*W*H)5500*3400*2900MM5500*3400*2900MM6000*4000*3700MM8000*3700*3600MM8000*4000*3700MM10500*4200*3500MM15000*4700*3600MM18000*4300*3700MM
Installed Power14KW21KW18KW21KW24KW35KW50KW66KW
Feed Temperature+15℃+15℃+15℃+15℃+15℃+15℃+15℃+15℃
Discharge Temperature-18℃-18℃-18℃-18℃-18℃-18℃-18℃-18℃
Circulating Temeprature-35±2℃-35±2℃-35±2℃-35±2℃-35±2℃-35±2℃-35±2℃-35±2℃
Freezing Time8~20Min8~20Min8~20Min8~20Min8~20Min8~20Min8~20Min8~20Min
RefrigerantsCustomizedCustomizedCustomizedCustomizedCustomizedCustomizedCustomizedCustomized
