Chocolate conching machine is one of the major machines for fine grinding chocolates. The chocolate conche has the functions of refining, grinding, deodorizing, dehydrating, etc. It is also easy to maintain, durable, leakproof, stable in performance, and energy saving.
Structure of chocolate conche machine
includes frame, mixing tank, rotating power source, rotating shaft and mixing blade, the upper and lower parts of the mixing tank are separately provided with inlet and outlet, the mixing tank is placed on the rack of the chocolate refiner, the rotating power source is installed on the outer wall of the mixing tank,
More details about the chocolate conching machine:
Double layers for hot water.
Motor: good brand Chinese motor
Electrics: Schneider or omron
Sticks and scrapers Material: 65#Mn steel after heat treatment with high strength, hardness and good abrasion resistence. Life is about 3 yeasrs with normal use.
Machine body: painted carbon steel
with temperature probe and temperature controller for automatically control.
Spare parts: 1pcs electrical heatings, some pcs linears, 1pcs scrapers, about 1 meter packing.
Parameter of Chocolate Conche Machine
Model | GG-CJM500 | GG-CJM1000 | GG-CJM2000 | GG-CJM3000 |
Maximum capacity(L) | 500 | 1000 | 2000 | 3000 |
Fine grinding size(μm) | 20-25 | 20-25 | 20-25 | 20-25 |
Fine grinding time(h) | 12-18 | 14-20 | 18-22 | 18-22 |
Power of motor(kw) | 15 | 22 | 37 | 37 |
Power of electric heater(kw) | 7.5 | 7.5 | 9 | 9 |
Weight(kg) | 3000 | 4250 | 5100 | 7000 |
Dimension(mm) | 2500*1080*1370 | 2780*1330*1800 | 3320*2000*1950 | 4200*2000*1950 |
