The shrink wrap machine is suitable for shrink packaging in stationery, food, cosmetics, pharmacy, hardware and other industries.
The shrink wrap machine uses imported PLC automatic program control is adopted, which is easy to operate and has safety protection and alarm functions, thus effectively preventing packages from being cut by mistake. Equipped with imported horizontal and vertical photoelectric detection, it is convenient to switch and select.
Shrink Wrap Machine Features:
1. Sealing strong and better performance of heat conduction. special durable alloyed sealing knife with anti-stick Teflon coats.
2. Easy to operate. only adjust packing width and height by hand wheels without changing any molds and parts when packing size changes. packing length can be detected by the sensor automatically.
3. Production line. Different products of different sizes can be packed together as a promotional package.
4. Quality key parts. Adopt Omron brand parts such as temperature controller, timer, relay, switch, and sensor.
5. Alarm for scrap film break or full.
6. A pair of photoelectric switches in vertical for thin products.
7. Optional closing conveyor for small products.
8. Optional sensor for transparent products.
9. Visible window in the shrink tunnel.
Shrink Wrap Machine Data:
| Model | GG-FL450 |
| Power | 380V/50-60Hz/3phase |
| Packaging Speed | 15 - 35 packs/min |
| Size of l-type sealing cutter | 570x480 mm |
| Packing height | 150 mm |
| Package Size | Width + height< 400mm, Length + height < 480mm |
| Packing Materials | POF,PE, Folded film |
| Maximum Film | 530mm (width ) x 280mm（Outer diameter） |
| Furnace Size | 1200(L) x 450(W) x 220(H) mm |
| Total Power | 8.5 kW |
| Platform Height | 780-850 mm |
| Pressure | 0.5MPa (5 bar) |
| Dimensions | 1600 x 770 x 1450mm 1600 x 600 x 1260mm |
| Weight | 450kgs |
